Chipset: Intel C612 series
CPU Pins: Supports Intel LGA2011-3 platform processors
Memory Slots: 8 DDR4 memory slots, supports server memory
Memory Standard: Supports quad-channel DDR4 2400/2133/1866MHz, maximum support 256GB
Storage Interfaces: 4 SATA 3.0 6Gbps hard drive interfaces, 4 sSATA 3.0 6Gbps hard drive interfaces
Expansion Slots: 2 PCI Express 3.0 x16 slots, 1 PCI Express 3.0 x4 slot, 2 PCI Express 3.0 x1 slots
Expansion Interfaces: 1 M.2 2280 NVMe PCIe x4 3.0 32Gbps, 1 M.2 2280 NVMe PCIe x4 2.0 20Gbps, 1 M.2 WIFI (NGFF Protocol) Interface
Onboard Audio Card: 7.1 Channel Audio Card
Onboard Network Card: Gigabit Ethernet Card
Power Interface: 24PIN + 8PIN
Fan Pins: 1 CPU_FAN Pin, 2 SYS_FAN Pins
Power Phases: 6-Phase Power Supply
PCB Layers: 10 Layers
Motherboard Size: 300*244MM ATX Form Factor
Rear Panel I/O: 1 PS/2 Keyboard/Mouse Port, 4 USB 2.0 Ports, 4 USB 3.0 Ports, 1 Network Port, 1 5-Pack Audio Port, 1 Optical Audio Port (integrated into the audio port)
Front Panel I/O: 2 USB 2.0 Pins (one set controls Wi-Fi and Bluetooth via jumpers), 1 USB 3.0 Pin, 1 Front Panel Audio Pin, 1 COM Pin, 1 Motherboard Buzzer, 1 Motherboard Diagnostic Card, 1 Power/Reset Button
